Use As A Floor Monitor; Rotate Tweeter By 90; Important - LD Systems ICOA Série Manuel D'utilisation

USE AS A FLOOR MONITOR

The speakers can also be used entirely as floor monitors thanks to the monitor DSP preset, the rotatable tweeter, and its all-purpose housing. Non-
slip rubber washers ensure secure positioning. The monitor angle is positioned at 55°.
ROTATE TWEETER BY 90°
The tweeter can be rotated 90° when the speaker needs to be used in situations where it is installed horizontally or used as a floor monitor.

IMPORTANT!

Warning: Risk of electric shock! Dangerous voltages present inside device! Opening the device and rotating the high-frequency horn
requires specialist knowledge and may only be carried out by specially trained personnel! If you are not suitably qualified, do not
attempt the procedure yourself. Refer instead to a qualified professional.
10
A
