Brydge SPX+ Mode D'emploi page 2

INSERT/REMOVE
TO INSERT: Place your Brydge on a flat surface and set
the hinges upright to 90 degrees. Insert your Surface
Pro X into the hinges, one side at a time, with the Wake
and Volume Buttons on top.
POWER
To manually power on, press and hold Fn + Bluetooth
keys. The light will turn green for 2 seconds to indicate
power.
PAIR
1. Turn on your Brydge SPX+
(Fn+Bluetooth), then press and
hold the Bluetooth key for three
seconds. The Bluetooth key
light will flash blue confirming
your Brydge is in pairing mode.
NOTE: If pairing takes longer than three minutes, the blue light will stop flashing and you will need to press the
Bluetooth button again.
CHARGE
TO CHECK BATTERY LIFE: go to Windows > Settings
> Devices > Bluetooth & other devices, and check the
battery level on 'Brydge SPX+'.
NOTE: If battery life is below 15%, the backlit key
functionality will be disabled to conserve remaining
battery life and the light on the Delete key will blink red.
SLEEP/WAKE
To conserve battery, your Brydge will enter sleep mode after 15 minutes of non-use. Press any key to wake it.
When you close your devices together, your Brydge will put your Surface Pro X into sleep mode. When you open your
devices, your Brydge will wake your Surface Pro X.
NOTE: Your Brydge will not put your Surface Pro X to sleep or wake it after 15 minutes of non-use.
TO REMOVE: Ensure your Brydge is on a flat surface.
Place your hand towards the back of the keyboard and
pull up on your Surface Pro X, one side at a time.
To manually power off, press and hold Fn + Bluetooth
keys for 2 seconds. The light will blink red momentarily
to indicate it's powered off.
2. On your Surface Pro X, select:
• Start
• Settings
• Devices
• Bluetooth & other devices
• Add Bluetooth or other device
• Bluetooth
• Brydge SPX+
TO CHARGE: Insert the charging cable into the
keyboard and plug the other end into a power source.
A solid red LED on the Bluetooth key indicates the
Brydge is charging.
When the keyboard is fully charged, the red LED will
turn off. A full charge can take up to three hours.
3. Type in the PIN on your
Brydge SPX+ and hit Enter.
