EN
5.2.5 Connect to the Grid via a Circuit Breaker.（Optional）
Please Note: This installation must be performed by a certified electrician to avoid risks of electric shock,
!
fire, or other hazards.
1. Put on Insulating gloves(Note: Gloves are not included and must be provided by the
electrician or user.)
2. Turn off circuit protection switches to avoid electric shock risk, ensure the circuit
breaker is turned off before starting the installation. Verify that there is no voltage at
the terminals using a multimeter. Only proceed with the installation after confirming
the absence of voltage.
3. Cut off the plug of the AC cable and strip the insulation from the three wires to
expose the copper.
4. Connect the power cable to the electrical panel:
(1) Connect the live wire to an available circuit breaker.
(2) Connect the neutral wire and ground wire to the neutral and ground bars in the household panel, respectively.
Three-phase power household installation diagram
10
ON
OFF
ON
OFF
